- MP2143 Datasheet
MP2143DJ-LF-Z Datasheet
Datasheet specifications
| Datasheet's name | MP2143 Datasheet |
|---|---|
| File size | 488.365 KB |
| File type | |
| Number of pages | 14 |
Download Datasheet MP2143 Datasheet |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Monolithic Power Systems Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 2.5V
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 0.6V
- Voltage - Output (Max): 5V
- Current - Output: 3A
- Frequency - Switching: 1.2MHz
- Synchronous Rectifier: Yes
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: SOT-23-8 Thin, TSOT-23-8
- Supplier Device Package: TSOT-23-8
- detail: Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 3A SOT-23-8 Thin, TSOT-23-8
