دیتاشیت IXTQ50N20P

IXT(A,P,Q)50N20P

مشخصات دیتاشیت

نام دیتاشیت IXT(A,P,Q)50N20P
حجم فایل 164.486 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت IXT(A,P,Q)50N20P

IXT(A,P,Q)50N20P Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: PolarHT™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 200V
  • Current - Continuous Drain (Id) @ 25°C: 50A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 60mOhm @ 50A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 70nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 2720pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 360W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-3P
  • Package / Case: TO-3P-3, SC-65-3
  • detail: N-Channel 200V 50A (Tc) 360W (Tc) Through Hole TO-3P
