دیتاشیت VBH40-05B
مشخصات دیتاشیت
نام دیتاشیت |
VBH40-05B
|
حجم فایل |
89.42
کیلوبایت
|
نوع فایل |
pdf
|
تعداد صفحات |
3
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
HiPerFET™
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
FET Type:
4 N-Channel (H-Bridge)
-
FET Feature:
Standard
-
Drain to Source Voltage (Vdss):
500V
-
Current - Continuous Drain (Id) @ 25°C:
40A
-
Rds On (Max) @ Id, Vgs:
116mOhm @ 30A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 8mA
-
Gate Charge (Qg) (Max) @ Vgs:
270nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
-
-
Power - Max:
-
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
V2-PAK
-
Supplier Device Package:
V2-PAK
-
detail:
Mosfet Array 4 N-Channel (H-Bridge) 500V 40A Chassis Mount V2-PAK
