دیتاشیت LM339ADR
مشخصات دیتاشیت
| نام دیتاشیت | LM139,239,339(A), LM2901(AV,V) |
|---|---|
| حجم فایل | 1275.688 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 33 |
دانلود دیتاشیت LM139,239,339(A), LM2901(AV,V) |
LM139,239,339(A), LM2901(AV,V) Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments LM339ADR
- Output Type: 开集;轨到轨
- Supply Current: 2.5mA
- Supply Voltage: 2V~30V;1V~15V
- Number of Elements: 4
- Operating Temperature: 0°C~+70°C
- Input Bias Current (Ib): 0.25uA
- Input Offset Voltage (Vos): 3mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): -
- Package: SOP-14
- Manufacturer: Texas Instruments
- Current - Output (Typ): 20mA
- Series: -
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Hysteresis: -
- CMRR, PSRR (Typ): -
- Voltage - Input Offset (Max): 3mV @ 30V
- Supplier Device Package: 14-SOIC
- Type: Differential
- Propagation Delay (Max): -
- Current - Quiescent (Max): 2.5mA
- Base Part Number: LM339
- Voltage - Supply, Single/Dual (±): 2V ~ 30V, ±1V ~ 15V
- Part Status: Active
- Packaging: Cut Tape (CT)
- Current - Input Bias (Max): 0.25µA @ 5V
- Mounting Type: Surface Mount
- detail: Comparator Differential CMOS, MOS, Open-Collector, TTL 14-SOIC
