دیتاشیت TL072CDR
مشخصات دیتاشیت
| نام دیتاشیت | TL071/A/B, TL072/A/B, TL074/A/B |
|---|---|
| حجم فایل | 2933.207 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 69 |
دانلود دیتاشیت TL071/A/B, TL072/A/B, TL074/A/B |
TL071/A/B, TL072/A/B, TL074/A/B Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/FET InputAmplifiers
- Datasheet: Texas Instruments TL072CDR
- Number of Circuits: 2
- Operating Temperature: 0°C~+70°C
- Current - Input Bias(Ib): 65pA
- Supply Current Per Channel: 1.4mA
- Gain Bandwidth Product(GBP): 5.25MHz
- Voltage - Input Offset(Vos): 3mV
- Package: SOP-8
- Manufacturer: Texas Instruments
- Slew Rate: 13V/µs
- Voltage - Input Offset: 3mV
- Part Status: Active
- Packaging: Tube
- Supplier Device Package: 8-SOIC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Voltage - Supply, Single/Dual (±): ±5V ~ 15V
- Series: -
- Output Type: -
- Base Part Number: TL072
- Current - Supply: 1.4mA
- Mounting Type: Surface Mount
- Amplifier Type: J-FET
- Current - Input Bias: 65pA
- Gain Bandwidth Product: 3MHz
- detail: J-FET Amplifier 2 Circuit 8-SOIC
