دیتاشیت TPD4E1B06DCKR
مشخصات دیتاشیت
| نام دیتاشیت | TPD4E1B06 Datasheet |
|---|---|
| حجم فایل | 1273.678 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 21 |
دانلود دیتاشیت TPD4E1B06 Datasheet |
TPD4E1B06 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: Texas Instruments TPD4E1B06DCKR
- Package: SOT-323-6
- Manufacturer: Texas Instruments
- Type: Steering (Rail to Rail)
- Packaging: Cut Tape (CT)
- Current - Peak Pulse (10/1000µs): 3A (8/20µs)
- Base Part Number: TPD4E
- Mounting Type: Surface Mount
- Voltage - Breakdown (Min): 7V
- Voltage - Clamping (Max) @ Ipp: 14.5V (Typ)
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Series: -
- Bidirectional Channels: 4
- Capacitance @ Frequency: -
- Supplier Device Package: SC-70-6
- Operating Temperature: -40°C ~ 125°C (TA)
- Applications: General Purpose
- Part Status: Active
- Power Line Protection: No
- Power - Peak Pulse: 45W
- Voltage - Reverse Standoff (Typ): 5.5V (Max)
- detail: 14.5V (Typ) Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount SC-70-6
