دیتاشیت TPD4E002DRLR

TPD4E002

مشخصات دیتاشیت

نام دیتاشیت TPD4E002
حجم فایل 949.337 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت TPD4E002

TPD4E002 Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Texas Instruments TPD4E002DRLR
  • Clamping Voltage@Ipp: -
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Breakdown Voltage (VBR): 6.1V
  • Peak Pulse Power(Ppp)@8/20us: 35W
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: -
  • Reverse Stand-Off Voltage (Vrwm): 3V
  • Package: SOT-5
  • Manufacturer: Texas Instruments
  • Type: Zener
  • Current - Peak Pulse (10/1000µs): -
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Clamping (Max) @ Ipp: -
  • Unidirectional Channels: 4
  • Package / Case: SOT-553
  • Series: -
  • Voltage - Reverse Standoff (Typ): 3V
  • Applications: General Purpose
  • Voltage - Breakdown (Min): 6.1V
  • Part Status: Active
  • Power - Peak Pulse: 35W
  • Base Part Number: TPD4E
  • Power Line Protection: No
  • Capacitance @ Frequency: -
  • Supplier Device Package: SOT-5
  • detail: Clamp Ipp Tvs Diode Surface Mount SOT-5
