ULN2003LVPWR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ULN2003LVPWR
|
|
حجم فایل
|
96.055
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
29
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Distribution Switches
-
Datasheet:
Texas Instruments ULN2003LVPWR
-
Package:
TSSOP-16
-
Manufacturer:
Texas Instruments
-
Base Part Number:
ULN2003
-
Current - Collector (Ic) (Max):
500mA
-
Supplier Device Package:
16-TSSOP
-
Packaging:
Cut Tape (CT)
-
Mounting Type:
Surface Mount
-
Current - Collector Cutoff (Max):
50µA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
-
-
Transistor Type:
7 NPN Darlington
-
Vce Saturation (Max) @ Ib, Ic:
1.6V @ 500µA, 350mA
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Frequency - Transition:
-
-
Series:
-
-
Part Status:
Active
-
Voltage - Collector Emitter Breakdown (Max):
50V
-
Power - Max:
-
-
detail:
Bipolar (BJT) Transistor Array 7 NPN Darlington 50V 500mA Surface Mount 16-TSSOP
