SN74LVC2G126 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC2G126 |
|---|---|
| حجم فایل | 1063.463 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت SN74LVC2G126 |
دانلود دیتاشیت |
|---|
سایر مستندات
TI SN74LVC2G126DCTR 24 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74LVC2G126DCTR
- Input type: -
- output type: Tri-State
- Logic Family: 74LVC
- Sink Current: 32mA
- Source Current: 32mA
- Supply Voltage: 1.65V~5.5V
- Number of Channels: 1
- Operating Temperature: -40°C~+125°C
- Package: SM8
- Manufacturer: Texas Instruments
- Logic Type: Buffer, Non-Inverting
- Current - Output High, Low: 32mA, 32mA
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Number of Bits per Element: 1
- Base Part Number: SN74LVC2G
- Number of Elements: 2
- Package / Case: 8-LSSOP, 8-MSOP (0.110", 2.80mm Width)
- Part Status: Active
- Series: 74LVC
- Voltage - Supply: 1.65V ~ 5.5V
- Supplier Device Package: SM8 (SSOP)
- detail: Buffer, Non-Inverting 2 Element 1 Bit per Element 3-State Output SM8 (SSOP)
