دیتاشیت SN74LVC4245APWR
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC4245A Datasheet |
|---|---|
| حجم فایل | 1027.445 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت SN74LVC4245A Datasheet |
SN74LVC4245A Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Logic ICs/Translators / Level Shifters
- Datasheet: Texas Instruments SN74LVC4245APWR
- Output Type: Tri-State
- Channel Type: Bi-Directional
- Number of Circuits: 1
- Channels per Circuit: 8
- Operating Temperature: -40°C~+85°C
- Supply Voltage (VCCA): 4.5V~5.5V
- Supply Voltage (VCCB): 2.7V~3.6V
- Package: TSSOP-24
- Manufacturer: Texas Instruments
- Base Part Number: SN74LVC42
- Output Signal: -
- Input Signal: -
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Translator Type: Voltage Level
- Features: -
- Package / Case: 24-TSSOP (0.173", 4.40mm Width)
- Part Status: Active
- Series: 74LVC
- Voltage - VCCB: 2.7V ~ 3.6V
- Voltage - VCCA: 4.5V ~ 5.5V
- Data Rate: -
- Supplier Device Package: 24-TSSOP
