دیتاشیت UA7805CKTTR
مشخصات دیتاشیت
| نام دیتاشیت | UA7805,08,10,12,15,24 |
|---|---|
| حجم فایل | 1119.424 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت UA7805,08,10,12,15,24 |
UA7805,08,10,12,15,24 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments UA7805CKTTR
- Output Current: 1.5A
- Output Voltage: 5V
- Dropout Voltage: 2V@(1A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 25V
- Operating Temperature: 0°C~+125°C
- Package: TO-263-3
- Manufacturer: Texas Instruments
- Number of Regulators: 1
- Base Part Number: UA780
- Voltage - Input (Max): 25V
- Supplier Device Package: DDPAK/TO-263-3
- Voltage - Output (Max): -
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Protection Features: Over Temperature, Reverse Polarity
- Control Features: -
- Voltage - Output (Min/Fixed): 5V
- Output Type: Fixed
- Voltage Dropout (Max): 2V @ 1A
- Part Status: Active
- Series: -
- Current - Output: 1.5A
- PSRR: 78dB ~ 68dB (120Hz)
- Output Configuration: Positive
- Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
- detail: Linear Voltage Regulator IC 1 Output 1.5A DDPAK/TO-263-3
