دیتاشیت ECMF02-2AMX6
مشخصات دیتاشیت
| نام دیتاشیت |
ECMF02-2AMX6
|
| حجم فایل |
1031.076
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Bead/Filter/EMI Optimization/Common Mode Filters
-
Datasheet:
STMicroelectronics ECMF02-2AMX6
-
Current Rating:
200mA
-
Number of Lines:
2
-
DC Resistance (DCR):
2.5Ω
-
Operating Temperature:
-40°C~+85°C
-
Package:
UFQFN-6(1.5x1.7)
-
Manufacturer:
STMicroelectronics
-
Series:
ECMF
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Filter Type:
Signal Line
-
Current Rating (Max):
200mA
-
DC Resistance (DCR) (Max):
2.5Ohm
-
Voltage Rating - DC:
-
-
Voltage Rating - AC:
-
-
Ratings:
-
-
Approval Agency:
-
-
Features:
ESD
-
Mounting Type:
Surface Mount
-
Size / Dimension:
0.067" L x 0.059" W (1.70mm x 1.50mm)
-
Height (Max):
0.022" (0.55mm)
-
Package / Case:
6-UFQFN
-
Base Part Number:
ECMF02
-
detail:
2 Line Common Mode Choke Surface Mount 200mA DCR 2.5Ohm
