دیتاشیت ULN2803ADWR

مشخصات دیتاشیت

دانلود دیتاشیت ULN2803A Datasheet	ULN2803A Datasheet Datasheet

RoHS: true
Category: Triode/MOS Tube/Transistor/Darlington Transistor Arrays
Datasheet: Texas Instruments ULN2803ADWR
Package: SOP-18-300mil
Manufacturer: Texas Instruments
Series: Automotive, AEC-Q100
Voltage - Collector Emitter Breakdown (Max): 50V
Current - Collector Cutoff (Max): -
Vce Saturation (Max) @ Ib, Ic: 1.6V @ 500µA, 350mA
Supplier Device Package: 18-SOIC
Mounting Type: Surface Mount
Base Part Number: ULN2803
Frequency - Transition: -
Current - Collector (Ic) (Max): 500mA
Packaging: Cut Tape (CT)
Transistor Type: 8 NPN Darlington
Power - Max: -
Package / Case: 18-SOIC (0.295", 7.50mm Width)
DC Current Gain (hFE) (Min) @ Ic, Vce: -
Operating Temperature: -40°C ~ 85°C (TA)
Part Status: Active
detail: Bipolar (BJT) Transistor Array 8 NPN Darlington 50V 500mA Surface Mount 18-SOIC
