دیتاشیت REF3333AIDBZR
مشخصات دیتاشیت
| نام دیتاشیت | REF3312,18,20,25,30,33 |
|---|---|
| حجم فایل | 1848.991 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 39 |
دانلود دیتاشیت REF3312,18,20,25,30,33 |
REF3312,18,20,25,30,33 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Texas Instruments REF3333AIDBZR
- Tolerance: ±0.15%
- Output Type: Fixed
- Input Voltage: 3.5V~5.5V
- Output Current: 5mA
- Output Voltage: 3.3V
- Reference Type: series connection
- Supply Current: 8.5uA
- Noise - 10Hz to 10kHz: -
- Operating Temperature: -40°C~+125°C@(Ta)
- Noise - 1/10Hz to 10Hz: 92uVp-p
- Temperature Coefficient: 30ppm/°C
- Package: SOT-23
- Manufacturer: Texas Instruments
- Voltage - Output (Min/Fixed): 3.3V
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Current - Supply: 8.5µA
- Noise - 0.1Hz to 10Hz: 92µVp-p
- Current - Output: 5mA
- Packaging: Cut Tape (CT)
- Supplier Device Package: SOT-23-3
- Part Status: Active
- Base Part Number: REF333
- Series: -
- Mounting Type: Surface Mount
- Voltage - Input: 3.5V ~ 5.5V
- detail: Series Voltage Reference IC ±0.15% SOT-23-3
