- TPS61165TDBVRQ1
TPS61165TDBVRQ1 Datasheet
Datasheet specifications
| Datasheet's name | TPS61165TDBVRQ1 |
|---|---|
| File size | 78.567 KB |
| File type | |
| Number of pages | 27 |
Download Datasheet TPS61165TDBVRQ1 |
Download Datasheet |
|---|
Other documentations
TPS61165-Q1 28 pages
Technical specifications
- RoHS: true
- Type: DC-DCVoltage Stabilizer
- Dimming: PWM
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Channels: 1
- Topology: boost converter
- Datasheet: Texas Instruments TPS61165TDBVRQ1
- Input Voltage: 3V~18V
- Output Current: 1.2A
- Output Voltage: 3V~38V
- Switch Frequency: 1.2MHz
- Operating temperature: -40°C~+105°C
- Package: SOT-23-6
- Manufacturer: Texas Instruments
- Voltage - Supply (Max): 18V
- Number of Outputs: 1
- Package / Case: SOT-23-6
- Applications: Automotive, Backlight
- Voltage - Output: 3V ~ 38V
- Frequency: 1.2MHz
- Packaging: Digi-Reel®
- Voltage - Supply (Min): 3V
- Part Status: Active
- Base Part Number: TPS611
- Series: Automotive, AEC-Q100
- Mounting Type: Surface Mount
- Internal Switch(s): Yes
- Current - Output / Channel: 1.2A (Switch)
- Supplier Device Package: SOT-23-6
- detail: LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) PWM Dimming 1.2A (Switch) SOT-23-6
