دیتاشیت TPS55340PWPR

مشخصات دیتاشیت

دانلود دیتاشیت TPS55340	TPS55340 Datasheet

Topology: Boost
Frequency - Switching: 94kHz ~ 1.14MHz
Number of Outputs: 1
Package / Case: 14-PowerTSSOP (0.173", 4.40mm Width)
Supplier Device Package: 14-HTSSOP
Voltage - Output (Min/Fixed): 2.9V
Current - Output: 5.25A (Switch)
Operating Temperature: -40°C ~ 125°C (TA)
Output Configuration: Positive, Isolation Capable
Packaging: Cut Tape (CT)
Function: Step-Up
Part Status: Active
Manufacturer: Texas Instruments
Voltage - Output (Max): 38V
Series: -
Mounting Type: Surface Mount
Voltage - Input (Max): 32V
Output Type: Adjustable
Base Part Number: TPS553
Voltage - Input (Min): 2.9V
Synchronous Rectifier: No
detail: Boost Switching Regulator IC Positive, Isolation Capable Adjustable 2.9V 1 Output 5.25A (Switch) 14-PowerTSSOP (0.173", 4.40mm Width)
