- REF3425IDBVR
REF3425IDBVR Datasheet
Datasheet specifications
| Datasheet's name | REF3425IDBVR |
|---|---|
| File size | 86.834 KB |
| File type | |
| Number of pages | 26 |
Download Datasheet REF3425IDBVR |
Download Datasheet |
|---|
Other documentations
REF3425, 3430, 3433, 3440, 3450 29 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Texas Instruments REF3425IDBVR
- Tolerance: ±0.05%
- Output Type: Fixed
- Input Voltage: 3V~12V
- Output Current: 10mA
- Output Voltage: 2.5V
- Reference Type: series connection
- Supply Current: 95uA
- Noise - 10Hz to 10kHz: 24uVrms
- Operating Temperature: -40°C~+125°C@(Ta)
- Noise - 1/10Hz to 10Hz: 5uVp-p
- Temperature Coefficient: 6ppm/°C
- Package: SOT-23-6
- Manufacturer: Texas Instruments
- Voltage - Output (Min/Fixed): 2.5V
- Package / Case: SOT-23-6
- Current - Supply: 95µA
- Noise - 0.1Hz to 10Hz: 5µVp-p
- Current - Output: 10mA
- Packaging: Cut Tape (CT)
- Supplier Device Package: SOT-23-6
- Part Status: Active
- Base Part Number: REF342
- Series: REF34xx
- Mounting Type: Surface Mount
- Voltage - Input: 3V ~ 12V
