DRV10983PWPR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | DRV10983PWPR |
|---|---|
| حجم فایل | 90.448 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 64 |
دانلود دیتاشیت DRV10983PWPR |
دانلود دیتاشیت |
|---|
سایر مستندات
DRV10983 Datasheet 61 pages
DRV10983 Tuning Guide 40 pages
مشخصات فنی
- RoHS: true
- Type: 无刷直流BLDC
- Category: Power Supply Chip/Motor Driver ICs
- Datasheet: Texas Instruments DRV10983PWPR
- Interface: I2C;PWM
- Output Current: 2A
- Supply Voltage: 8V~28V
- Operating Temperature: -40°C~+125°C@(Tj)
- Package: TSSOP-24-EP
- Manufacturer: Texas Instruments
- Base Part Number: DRV10983
- Motor Type - Stepper: -
- Package / Case: 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Applications: Appliance
- Supplier Device Package: 24-HTSSOP
- Current - Output: 2A
- Voltage - Load: 8V ~ 28V
- Output Configuration: Half Bridge (3)
- Packaging: Cut Tape (CT)
- Function: Driver - Fully Integrated, Control and Power Stage
- Step Resolution: -
- Part Status: Active
- Series: -
- Mounting Type: Surface Mount
- Motor Type - AC, DC: Brushless DC (BLDC)
- Voltage - Supply: 8V ~ 28V
- Technology: Power MOSFET
- detail: Motor Driver Power MOSFET Analog, I²C, PWM 24-HTSSOP
