Analog Signal Chain Guide Datasheet

Analog Signal Chain Guide

Datasheet specifications

Datasheet's name Analog Signal Chain Guide
File size 1059.19 KB
File type pdf
Number of pages 11

Download Datasheet Analog Signal Chain Guide

Download Datasheet

Other documentations

REF5020,25,30,40,45,50 Datasheet 40 pages

Technical specifications

  • Part Status: Active
  • Current - Supply: 1.2mA
  • Current - Output: 10mA
  • Series: -
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Voltage - Output (Min/Fixed): 3V
  • Base Part Number: REF503
  • Mounting Type: Surface Mount
  • Noise - 10Hz to 10kHz: -
  • Reference Type: Series
  • Noise - 0.1Hz to 10Hz: 3µVp-p
  • Voltage - Input: 3.2V ~ 18V
  • Tolerance: ±0.05%
  • Packaging: Cut Tape (CT)
  • Manufacturer: Texas Instruments
  • Output Type: Fixed
  • Supplier Device Package: 8-VSSOP
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Temperature Coefficient: 3ppm/°C
  • detail: Series Voltage Reference IC ±0.05% 8-VSSOP
