دیتاشیت LDL1117S33R

مشخصات دیتاشیت

LDL1117S33R	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: STMicroelectronics LDL1117S33R
Output Type: Fixed
Output Current: 1.2A
Output Voltage: 3.3V
Dropout Voltage: 600mV@(1.2A)
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 18V
Operating Temperature: -40°C~+125°C@(Tj)
Quiescent Current (Ground Current): 500uA
Power Supply Rejection Ratio (PSRR): 87dB@(120Hz),65dB@(100kHz)
Package: SOT-223-4
Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Number of Regulators: 1
Voltage - Input (Max): 18V
Voltage - Output (Min/Fixed): 3.3V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.6V @ 1.2A
Current - Output: 1.2A
Current - Quiescent (Iq): 500µA
PSRR: 87dB ~ 65dB (120Hz ~ 100kHz)
Control Features: -
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Mounting Type: Surface Mount
Package / Case: TO-261-4, TO-261AA
Supplier Device Package: SOT-223
Base Part Number: LDL1117
detail: Linear Voltage Regulator IC 1 Output 1.2A SOT-223
