دیتاشیت ADS1232IPWR
مشخصات دیتاشیت
| نام دیتاشیت | ADS1232, ADS1234 Datasheet |
|---|---|
| حجم فایل | 1252.518 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 39 |
دانلود دیتاشیت ADS1232, ADS1234 Datasheet |
ADS1232, ADS1234 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS1232IPWR
- Interface: SPI
- resolution: 24Bit
- Supply Voltage: 2.7V~5.3V
- differential input: Yes
- number of channels: 2
- sampling frequency: 80Hz
- Operating Temperature: -40°C~+105°C
- Package: TSSOP-24
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Voltage - Supply, Digital: 2.7V ~ 5.3V
- Input Type: Differential, Single Ended
- Architecture: Sigma-Delta
- Packaging: Cut Tape (CT)
- Number of Bits: 24
- Data Interface: SPI
- Number of Inputs: 2
- Supplier Device Package: 24-TSSOP
- Ratio - S/H:ADC: -
- Sampling Rate (Per Second): 80
- Number of A/D Converters: 1
- Part Status: Active
- Package / Case: 24-TSSOP (0.173", 4.40mm Width)
- Voltage - Supply, Analog: 2.7V ~ 5.3V
- Reference Type: External
- Base Part Number: ADS1232
- Series: -
- Features: PGA
- Configuration: MUX-PGA-ADC
- detail: 24 Bit Analog to Digital Converter 2 Input 1 Sigma-Delta 24-TSSOP
