دیتاشیت ADS1247IPWR
مشخصات دیتاشیت
| نام دیتاشیت | ADS1247IPWR |
|---|---|
| حجم فایل | 122.743 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 70 |
ADS1247IPWR |
دانلود دیتاشیت |
|---|
سایر مستندات
Analog Signal Chain Guide 11 pages
ADS1246-48 103 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS1247IPWR
- Interface: SPI
- resolution: 24Bit
- Supply Voltage: 2.7V~5.25V
- differential input: Yes
- number of channels: 2;3
- sampling frequency: 2kHz
- Operating Temperature: -40°C~+105°C
- Package: TSSOP-20
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Voltage - Supply, Digital: 2.7V ~ 5.25V
- Input Type: Differential, Single Ended
- Architecture: Sigma-Delta
- Packaging: Cut Tape (CT)
- Number of Bits: 24
- Data Interface: SPI
- Number of Inputs: 2, 3
- Supplier Device Package: 20-TSSOP
- Ratio - S/H:ADC: -
- Sampling Rate (Per Second): 2k
- Number of A/D Converters: 1
- Part Status: Active
- Package / Case: 20-TSSOP (0.173", 4.40mm Width)
- Voltage - Supply, Analog: 2.7V ~ 5.25V
- Reference Type: External, Internal
- Base Part Number: ADS1247
- Series: -
- Features: PGA, Temperature Sensor
- Configuration: MUX-PGA-ADC
- detail: 24 Bit Analog to Digital Converter 2, 3 Input 1 Sigma-Delta 20-TSSOP
