دیتاشیت STM32L010K4T6
مشخصات دیتاشیت
| نام دیتاشیت | STM32L010F4, STM32L010K4 |
|---|---|
| حجم فایل | 1877.885 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 91 |
دانلود دیتاشیت STM32L010F4, STM32L010K4 |
STM32L010F4, STM32L010K4 Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M0
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 2KB
- Watchdog: -
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: STMicroelectronics STM32L010K4T6
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 26
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 16KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-32(7x7)
- Manufacturer: STMicroelectronics
- Series: STM32L0
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M0+
- Core Size: 32-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
- Number of I/O: 26
- Program Memory Size: 16KB (16K x 8)
- EEPROM Size: 128 x 8
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Data Converters: A/D 10x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 32-LQFP
- Supplier Device Package: 32-LQFP (7x7)
- Base Part Number: STM32L010
- detail: ARM® Cortex®-M0+ STM32L0 Microcontroller IC 32-Bit 32MHz 16KB (16K x 8) FLASH 32-LQFP (7x7)
