دیتاشیت STPS2045CT
مشخصات دیتاشیت
| نام دیتاشیت |
STPS2045C
|
| حجم فایل |
545.117
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
STMicroelectronics STPS2045CT
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
45V
-
Forward Voltage (Vf@If):
570mV@10A
-
Reverse Leakage Current (Ir):
100uA@45V
-
Average Rectified Current (Io):
10A
-
Package:
TO-220AB-3
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
45V
-
Current - Average Rectified (Io) (per Diode):
10A
-
Voltage - Forward (Vf) (Max) @ If:
570mV @ 10A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
100µA @ 45V
-
Operating Temperature - Junction:
175°C (Max)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220AB
-
Base Part Number:
STPS2045
-
detail:
Diode Array 1 Pair Common Cathode Schottky 45V 10A Through Hole TO-220-3
