دیتاشیت PTH08080WAH
مشخصات دیتاشیت
| نام دیتاشیت |
PTH08080W
|
| حجم فایل |
510.011
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
18
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Function:
-
-
Datasheet:
Texas Instruments PTH08080WAH
-
Output Channel:
1
-
Output Voltage:
0.9V~5.5V
-
Conversion Type:
DC-DC
-
Input Voltage(DC):
4.5V~18V
-
Output Current (Max):
2.25A
-
Conversion Efficiency:
93.5%
-
Package:
EUF-5
-
Manufacturer:
Texas Instruments
-
Type:
Non-Isolated PoL Module
-
Efficiency:
93.5%
-
Voltage - Output 2:
-
-
Mounting Type:
Through Hole
-
Package / Case:
5-DIP Module
-
Series:
PTH08080W
-
Number of Outputs:
1
-
Voltage - Input (Min):
4.5V
-
Part Status:
Active
-
Base Part Number:
PTH08
-
Current - Output (Max):
2.25A
-
Packaging:
Tray
-
Voltage - Output 3:
-
-
Features:
-
-
Voltage - Output 1:
0.9 ~ 5.5V
-
Size / Dimension:
0.60" L x 0.50" W x 0.32" H (15.2mm x 12.7mm x 8.1mm)
-
Operating Temperature:
-40°C ~ 85°C
-
Voltage - Input (Max):
18V
-
Applications:
ITE (Commercial)
-
detail:
Non-Isolated PoL Module DC DC Converter 1 Output 0.9 ~ 5.5V 2.25A 4.5V - 18V Input
