- دیتاشیت AMC1301DWVR
AMC1301DWVR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | AMC1301DWVR |
|---|---|
| حجم فایل | 110.02 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت AMC1301DWVR |
دانلود دیتاشیت |
|---|
سایر مستندات
AMC1301 Datasheet 35 pages
Understanding Isolation Terminology 2 pages
AMC130x High-Voltage Isolation Quality & Reliability 6 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Isolation Amplifiers
- Datasheet: Texas Instruments AMC1301DWVR
- Bandwidth (-3dB): -
- Number of Channels: 1
- Operating Temperature: -40°C~+125°C
- Input Bias Current (Ib): 60uA
- Input Offset Voltage (Vos): 50uV
- Gain Bandwidth Product (GBP): 1MHz
- Package: SOP-8-300mil
- Manufacturer: Texas Instruments
- Voltage - Input Offset: 50µV
- Current - Supply: 5.9mA
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.295", 7.50mm Width)
- Amplifier Type: Isolation
- Series: -
- Base Part Number: AMC1301
- Part Status: Active
- Gain Bandwidth Product: 1MHz
- Current - Input Bias: 60µA
- Voltage - Supply, Single/Dual (±): 3V ~ 5.5V
- Number of Circuits: 1
- Packaging: Cut Tape (CT)
- Output Type: -
- Supplier Device Package: 8-SOIC
- Slew Rate: -
- Current - Output / Channel: 13mA
- detail: Isolation Amplifier 1 Circuit 8-SOIC
