ADS8325IDGKT Datasheet

ADS8325

Datasheet specifications

Datasheet's name ADS8325
File size 1619.494 KB
File type pdf
Number of pages 36

Download Datasheet ADS8325

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Mounting Type: Surface Mount
  • Voltage - Supply, Digital: 2.7V ~ 3.6V, 5V
  • Input Type: Pseudo-Differential, Single Ended
  • Architecture: SAR
  • Packaging: Cut Tape (CT)
  • Number of Bits: 16
  • Data Interface: SPI
  • Number of Inputs: 1
  • Supplier Device Package: 8-VSSOP
  • Operating Temperature: -40°C ~ 85°C
  • Ratio - S/H:ADC: 1:1
  • Sampling Rate (Per Second): 100k
  • Number of A/D Converters: 1
  • Part Status: Active
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Voltage - Supply, Analog: 2.7V ~ 3.6V, 5V
  • Reference Type: External
  • Base Part Number: ADS8325
  • Series: microPOWER™
  • Manufacturer: Texas Instruments
  • Features: -
  • Configuration: S/H-ADC
  • detail: 16 Bit Analog to Digital Converter 1 Input 1 SAR 8-VSSOP
