INA114BP دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
INA114BP
|
|
حجم فایل
|
74.226
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
17
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Instrumentation OpAmps
-
Datasheet:
Texas Instruments INA114BP
-
-3db Bandwidth:
1MHz
-
Number of Circuits:
1
-
Operating Temperature:
-40°C~+85°C
-
Current - Input Bias(Ib):
500pA
-
Gain Bandwidth Product(GBP):
-
-
Voltage - Input Offset(Vos):
10uV
-
Package:
PDIP-8
-
Manufacturer:
Texas Instruments
-
Voltage - Input Offset:
10µV
-
Current - Supply:
2.2mA
-
Mounting Type:
Through Hole
-
Package / Case:
8-DIP (0.300", 7.62mm)
-
Amplifier Type:
Instrumentation
-
Series:
-
-
Base Part Number:
INA114
-
Part Status:
Active
-
Current - Input Bias:
500pA
-
Voltage - Supply, Single/Dual (±):
4.5V ~ 36V, ±2.25V ~ 18V
-
Packaging:
Tube
-
Output Type:
-
-
Supplier Device Package:
8-PDIP
-
Slew Rate:
0.6V/µs
-
Current - Output / Channel:
20mA
-
detail:
Instrumentation Amplifier 1 Circuit 8-PDIP
