دیتاشیت VIPER16HD

VIPER16

مشخصات دیتاشیت

نام دیتاشیت VIPER16
حجم فایل 1261.407 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت VIPER16

VIPER16 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Step-down;Step-down-Boost;Flyback
  • Datasheet: STMicroelectronics VIPER16HD
  • Duty Cycle: 70%
  • Supply Voltage: 11.5V~23.5V
  • Breakdown Voltage: 800V
  • Switching Frequency: 115kHz
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: SOP-16
  • Manufacturer: STMicroelectronics
  • Series: VIPer™ plus
  • Packaging: Tube
  • Part Status: Active
  • Output Isolation: Either
  • Internal Switch(s): Yes
  • Voltage - Breakdown: 800V
  • Voltage - Start Up: 13V
  • Voltage - Supply (Vcc/Vdd): 11.5V ~ 23.5V
  • Frequency - Switching: 115kHz
  • Power (Watts): 10W
  • Fault Protection: Current Limiting, Over Temperature
  • Control Features: -
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SO
  • Mounting Type: Surface Mount
  • Base Part Number: VIPER16
