دیتاشیت OPA544T
مشخصات دیتاشیت
| نام دیتاشیت | OPA544T |
|---|---|
| حجم فایل | 71.067 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
OPA544T |
دانلود دیتاشیت |
|---|
سایر مستندات
Analog Signal Chain Guide 11 pages
OPA544 Datasheet 17 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Texas Instruments OPA544T
- -3db Bandwidth: -
- Output Current: 2A
- Number of Circuits: 1
- Operating Temperature: -40°C~+85°C
- Current - Input Bias(Ib): 15pA
- Gain Bandwidth Product(GBP): 1.4MHz
- Package: TO-220-5
- Manufacturer: Texas Instruments
- Voltage - Input Offset: 1mV
- Current - Supply: 12mA
- Mounting Type: Through Hole
- Package / Case: TO-220-5
- Amplifier Type: Power
- Series: -
- Base Part Number: OPA544
- Part Status: Active
- Gain Bandwidth Product: 1.4MHz
- Current - Input Bias: 15pA
- Voltage - Supply, Single/Dual (±): 20V ~ 70V, ±10V ~ 35V
- Packaging: Tube
- Output Type: -
- Supplier Device Package: TO-220-5
- Slew Rate: 8V/µs
- Current - Output / Channel: 4A
- detail: Power Amplifier 1 Circuit TO-220-5
