ADS1262,ADS1263 Datasheet دیتاشیت

ADS1262,ADS1263 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADS1262,ADS1263 Datasheet
حجم فایل 2845.793 کیلوبایت
نوع فایل pdf
تعداد صفحات 133

مشاهده دیتاشیت ADS1262,ADS1263 Datasheet

دانلود دیتاشیت

سایر مستندات

TI Components for Space,Avionics,Defense 25 pages

ADS1262IPWR 136 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments ADS1262IPWR
  • Interface: SPI
  • resolution: 32Bit
  • Supply Voltage: 4.75V~5.25V
  • differential input: Yes
  • number of channels: 11
  • sampling frequency: 38kHz
  • Operating Temperature: -40°C~+125°C
  • Package: TSSOP-28
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Voltage - Supply, Digital: 2.7V ~ 5.25V
  • Input Type: Differential, Single Ended
  • Architecture: Sigma-Delta
  • Packaging: Cut Tape (CT)
  • Number of Bits: 32
  • Data Interface: SPI
  • Number of Inputs: 11
  • Supplier Device Package: 28-TSSOP
  • Ratio - S/H:ADC: 0:1
  • Sampling Rate (Per Second): 38k
  • Number of A/D Converters: 1
  • Part Status: Active
  • Package / Case: 28-TSSOP (0.173", 4.40mm Width)
  • Voltage - Supply, Analog: 4.75V ~ 5.25V
  • Reference Type: External, Internal
  • Base Part Number: ADS1262
  • Series: -
  • Features: PGA, Temperature Sensor
  • Configuration: MUX-PGA-ADC
  • detail: 32 Bit Analog to Digital Converter 11 Input 1 Sigma-Delta 28-TSSOP
