دیتاشیت ADS1262IPWR
مشخصات دیتاشیت
| نام دیتاشیت | ADS1262,ADS1263 Datasheet |
|---|---|
| حجم فایل | 2845.793 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 133 |
دانلود دیتاشیت ADS1262,ADS1263 Datasheet |
ADS1262,ADS1263 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS1262IPWR
- Interface: SPI
- resolution: 32Bit
- Supply Voltage: 4.75V~5.25V
- differential input: Yes
- number of channels: 11
- sampling frequency: 38kHz
- Operating Temperature: -40°C~+125°C
- Package: TSSOP-28
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Voltage - Supply, Digital: 2.7V ~ 5.25V
- Input Type: Differential, Single Ended
- Architecture: Sigma-Delta
- Packaging: Cut Tape (CT)
- Number of Bits: 32
- Data Interface: SPI
- Number of Inputs: 11
- Supplier Device Package: 28-TSSOP
- Ratio - S/H:ADC: 0:1
- Sampling Rate (Per Second): 38k
- Number of A/D Converters: 1
- Part Status: Active
- Package / Case: 28-TSSOP (0.173", 4.40mm Width)
- Voltage - Supply, Analog: 4.75V ~ 5.25V
- Reference Type: External, Internal
- Base Part Number: ADS1262
- Series: -
- Features: PGA, Temperature Sensor
- Configuration: MUX-PGA-ADC
- detail: 32 Bit Analog to Digital Converter 11 Input 1 Sigma-Delta 28-TSSOP
