دیتاشیت TMS320F28335PTPS

مشخصات دیتاشیت

دانلود دیتاشیت TMS320F2833x, 2823x Datasheet	TMS320F2833x, 2823x Datasheet Datasheet

RoHS: true
CPU Core: Other series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
Datasheet: Texas Instruments TMS320F28335PTPS
CPU Maximum Speed: 150MHz
GPIO Ports Number: 88
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Direct Memory Access: Yes
Program Storage Size: 512KB
Operating Voltage Range: 1.805V~1.995V
Operating Temperature Range: -40°C~+125°C
Package: LQFP-176(24x24)
Manufacturer: Texas Instruments
Mounting Type: Surface Mount
RAM Size: 34K x 16
Connectivity: CANbus, EBI/EMI, I²C, McBSP, SCI, SPI, UART/USART
Packaging: Tray
Data Converters: A/D 16x12b
Number of I/O: 88
Core Size: 32-Bit
Core Processor: C28x
Supplier Device Package: 176-HLQFP (24x24)
Operating Temperature: -40°C ~ 125°C (TA)
Part Status: Active
EEPROM Size: -
Package / Case: 176-LQFP Exposed Pad
Voltage - Supply (Vcc/Vdd): 1.805V ~ 1.995V
Program Memory Size: 512KB (256K x 16)
Base Part Number: TMS320
Speed: 150MHz
Series: C2000™ C28x Delfino™
Oscillator Type: Internal
Program Memory Type: FLASH
Peripherals: DMA, POR, PWM, WDT
detail: C28x C2000™ C28x Delfino™ Microcontroller IC 32-Bit 150MHz 512KB (256K x 16) FLASH 176-HLQFP (24x24)
