دیتاشیت MC9S08QE32CLD

مشخصات دیتاشیت

دانلود دیتاشیت MC9S08QE16,32 Series	MC9S08QE16,32 Series Datasheet

RoHS: true
EEPROM: -
CPU Core: Other series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
RAM Size: 2KB
Watchdog: Yes
ADC (Bit): 12bit
DAC (Bit): -
Datasheet: NXP Semicon MC9S08QE32CLD
PWM (Bit): -
Real-Time Clock: -
CPU Maximum Speed: 50MHz
GPIO Ports Number: 34
Low-Voltage Detect: Yes
CCP Capture/Compare: -
Internal Comparator: -
Internal Oscillator: Yes
Peripheral/Function: PWM
Program Memory Type: FLASH
Direct Memory Access: -
Program Storage Size: 32KB
Universal Serial Bus: -
communication protocol: -
Operating Voltage Range: 1.8V~3.6V
Infrared Data Association: -
Operating Temperature Range: -40°C~+85°C
Secure Digital Input and Output: -
Package: LQFP-44(10x10)
Manufacturer: NXP Semicon
Series: S08
Packaging: Tray
Part Status: Active
Core Processor: S08
Core Size: 8-Bit
Speed: 50MHz
Connectivity: I²C, LINbus, SCI, SPI
Peripherals: LVD, PWM, WDT
Number of I/O: 34
Program Memory Size: 32KB (32K x 8)
EEPROM Size: -
Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
Data Converters: A/D 10x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 44-LQFP
Supplier Device Package: 44-LQFP (10x10)
Base Part Number: MC9S0
detail: S08 S08 Microcontroller IC 8-Bit 50MHz 32KB (32K x 8) FLASH 44-LQFP (10x10)
