TS3A4751PWR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TS3A4751PWR
|
|
حجم فایل
|
87.799
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
28
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TS3A4751PWR
-
Turn-on time:
14ns
-
Turn-off time:
9ns
-
Supply Voltage:
1.6V~3.6V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
4
-
On-State Resistance (Max):
900mΩ
-
Package:
TSSOP-14
-
Manufacturer:
Texas Instruments
-
Base Part Number:
TS3A47
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
-
Charge Injection:
3pC
-
Part Status:
Active
-
Series:
-
-
Mounting Type:
Surface Mount
-
Current - Leakage (IS(off)) (Max):
2nA
-
Number of Circuits:
4
-
Voltage - Supply, Single (V+):
1.6V ~ 3.6V
-
Voltage - Supply, Dual (V±):
-
-
-3db Bandwidth:
125MHz
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Supplier Device Package:
14-TSSOP
-
Crosstalk:
-95dB @ 1MHz
-
Switch Time (Ton, Toff) (Max):
14ns, 9ns
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Packaging:
Cut Tape (CT)
-
Channel-to-Channel Matching (ΔRon):
30mOhm
-
Channel Capacitance (CS(off), CD(off)):
23pF, 20pF
-
detail:
4 Circuit IC Switch 1:1 900mOhm 14-TSSOP
