دیتاشیت TC115501EMTTR
مشخصات دیتاشیت
| نام دیتاشیت |
TC115
|
| حجم فایل |
223.984
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
14
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Microchip Tech TC115501EMTTR
-
Output Type:
Fixed
-
Input Voltage:
0.9V~10V
-
Output Voltage:
5V
-
Number of Outputs:
1
-
Switching Frequency:
100kHz
-
Output Current (Max):
100mA
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
SOT-89-5
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
0.9V
-
Voltage - Input (Max):
10V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Current - Output:
100mA
-
Frequency - Switching:
100kHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-89-5/6
-
Supplier Device Package:
SOT-89-5
-
Base Part Number:
TC115
-
detail:
Boost Switching Regulator IC Positive Fixed 5V 1 Output 100mA SOT-89-5/6
