دیتاشیت BC857BDW1T1G
مشخصات دیتاشیت
| نام دیتاشیت | BC85(6, 7, 8)xDW1T1 Series |
|---|---|
| حجم فایل | 84.756 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت BC85(6, 7, 8)xDW1T1 Series |
BC85(6, 7, 8)xDW1T1 Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: onsemi BC857BDW1T1G
- Transistor Type: 2PCSPNP
- Operating Temperature: -55°C~+150°C@(Tj)
- Collector Current (Ic): 100mA
- Power Dissipation (Pd): 380mW
- Transition Frequency (fT): 100MHz
- DC Current Gain (hFE@Ic,Vce): 220@2mA,5V
- Collector Cut-Off Current (Icbo): 15nA
- Collector-Emitter Breakdown Voltage (Vceo): 45V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 650mV@100mA,5mA
- Package: SOT-363-6(SC-70-6)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Current - Collector (Ic) (Max): 100mA
- Voltage - Collector Emitter Breakdown (Max): 45V
- Vce Saturation (Max) @ Ib, Ic: 650mV @ 5mA, 100mA
- Current - Collector Cutoff (Max): 15nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 220 @ 2mA, 5V
- Power - Max: 380mW
- Frequency - Transition: 100MHz
- Mounting Type: Surface Mount
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Supplier Device Package: SC-88/SC70-6/SOT-363
- Base Part Number: BC857
