دیتاشیت NCP603SN330T1G

NCP603

مشخصات دیتاشیت

نام دیتاشیت NCP603
حجم فایل 169.992 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت NCP603

NCP603 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 6V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.23V @ 300mA
  • Current - Output: 300mA
  • Current - Quiescent (Iq): 180µA
  • PSRR: 62dB ~ 38dB (120Hz ~ 10kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Transient Voltage
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: 5-TSOP
  • Base Part Number: NCP603
  • detail: Linear Voltage Regulator IC 1 Output 300mA 5-TSOP
