- دیتاشیت MC34063AP1G
MC34063AP1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MC34063AP1G |
|---|---|
| حجم فایل | 84.208 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت MC34063AP1G |
دانلود دیتاشیت |
|---|
سایر مستندات
MC3x063A, SC3x063A, NCV33063A 17 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType;Step-down type
- Topology: Step-down;Boost
- Datasheet: onsemi MC34063AP1G
- Output Type: Adjustable
- Input Voltage: 3V~40V
- Output Voltage: 1.25V~40V
- Number of Outputs: 1
- Switching Frequency: 100kHz
- Output Current (Max): 1.5A
- Operating Temperature: 0°C~+70°C@(TA)
- Synchronous Rectification: NO
- Package: DIP-8
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive or Negative
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 1.25V
- Voltage - Output (Max): 40V (Switch)
- Current - Output: 1.5A (Switch)
- Frequency - Switching: 100kHz
- Synchronous Rectifier: No
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: MC34063
- detail: Buck, Boost Switching Regulator IC Positive or Negative Adjustable 1.25V 1 Output 1.5A (Switch) 8-DIP (0.300", 7.62mm)
