دیتاشیت HCPL4503M
مشخصات دیتاشیت
| نام دیتاشیت | 6N135M-36M, HCPL4503M HCPL2530M-31M |
|---|---|
| حجم فایل | 680.14 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت 6N135M-36M, HCPL4503M HCPL2530M-31M |
6N135M-36M, HCPL4503M HCPL2530M-31M Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
- Data Rate: 1Mbit/s
- Datasheet: onsemi HCPL4503M
- Input Type: DC
- Supply Voltage: 4.5V~20V
- Number of Channels: 1
- Operating Temperature: -40°C~+100°C
- Isolation Voltage(rms): 2500V
- Propagation Delay tpLH/tpHL: 0.8us
- Common Mode Transient Immunity (CMTI): 15kV/us
- Package: DIP-8
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Voltage - Isolation: 5000Vrms
- Current Transfer Ratio (Min): 19% @ 16mA
- Current Transfer Ratio (Max): 50% @ 16mA
- Turn On / Turn Off Time (Typ): 250ns, 260ns
- Rise / Fall Time (Typ): -
- Output Type: Transistor with Base
- Voltage - Output (Max): 20V
- Current - Output / Channel: 8mA
- Voltage - Forward (Vf) (Typ): 1.45V
- Current - DC Forward (If) (Max): 25mA
- Vce Saturation (Max): -
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-DIP
- Base Part Number: HCPL45
- detail: Optoisolator Transistor with Base Output 5000Vrms 1 Channel 8-DIP
