دیتاشیت MBR0530

MBR0530

مشخصات دیتاشیت

نام دیتاشیت MBR0530
حجم فایل 75.754 کیلوبایت
نوع فایل pdf
تعداد صفحات 2

دانلود دیتاشیت MBR0530

MBR0530 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: LGE MBR0530
  • Reverse Voltage (Vr): 30V
  • Forward Voltage (Vf@If): 0.55V@0.5A
  • Reverse Leakage Current (Ir): 20uA@30V
  • Average Rectified Current (Io): 0.5A
  • Package: SOD-123FL
  • Manufacturer: LGE
  • Diode Configuration: -
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Last Time Buy
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30V
  • Current - Average Rectified (Io): 500mA
  • Voltage - Forward (Vf) (Max) @ If: 430mV @ 500mA
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 130µA @ 30V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: SOD-123
  • Supplier Device Package: SOD-123
  • Operating Temperature - Junction: -65°C ~ 125°C
  • Base Part Number: MBR0530
