دیتاشیت M1MA152WKT1G

مشخصات دیتاشیت

دانلود دیتاشیت M1MA15xWKT1, SM1MA151WKT1G	M1MA15xWKT1, SM1MA151WKT1G Datasheet

RoHS: true
Category: Diodes/Switching Diode
Datasheet: onsemi M1MA152WKT1G
Power Dissipation: 150mW
Diode Configuration: Dual Common Cathode
Reverse Voltage (Vr): 80V
Operating Temperature: +150°C@(Tj)
Forward Voltage (Vf@If): 1.2V@100mA
Reverse Leakage Current: 100nA@75V
Reverse Recovery Time (trr): 3ns
Average Rectified Current (Io): 100mA
Package: SC-59
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Diode Type: Standard
Voltage - DC Reverse (Vr) (Max): 80V
Current - Average Rectified (Io) (per Diode): 100mA (DC)
Voltage - Forward (Vf) (Max) @ If: 1.2V @ 100mA
Speed: Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr: 100nA @ 75V
Operating Temperature - Junction: 150°C (Max)
Mounting Type: Surface Mount
Package / Case: TO-236-3, SC-59, SOT-23-3
Supplier Device Package: SC-59
Base Part Number: M1MA152
detail: Diode Array 1 Pair Common Cathode Standard 80V 100mA (DC) Surface Mount TO-236-3, SC-59, SOT-23-3
