دیتاشیت SZESD7205DT5G

ESD7205, SZESD7205

مشخصات دیتاشیت

نام دیتاشیت ESD7205, SZESD7205
حجم فایل 175.071 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت ESD7205, SZESD7205

ESD7205, SZESD7205 Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi SZESD7205DT5G
  • Package: SOT-723-3
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 2
  • Voltage - Reverse Standoff (Typ): 5V (Max)
  • Voltage - Breakdown (Min): 5.2V
  • Voltage - Clamping (Max) @ Ipp: 12.5V (Typ)
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: Ethernet, USB OTG
  • Capacitance @ Frequency: 0.34pF @ 1MHz
  • Operating Temperature: -55°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: SOT-723
  • Supplier Device Package: SOT-723
  • Base Part Number: ESD72
  • detail: 12.5V (Typ) Clamp Ipp Tvs Diode Surface Mount SOT-723
