دیتاشیت ISL9R18120S3ST
مشخصات دیتاشیت
| نام دیتاشیت |
ISL9R18120S3ST
|
| حجم فایل |
68.964
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Diodes - General Purpose
-
Datasheet:
onsemi ISL9R18120S3ST
-
Diode Configuration:
-
-
Reverse Voltage (Vr):
1.2kV
-
Forward Voltage (Vf@If):
3.3V@18A
-
Reverse Leakage Current:
-
-
Average Rectified Current (Io):
18A
-
Package:
TO-263AB
-
Manufacturer:
onsemi
-
Series:
Stealth™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
1200V
-
Current - Average Rectified (Io):
18A
-
Voltage - Forward (Vf) (Max) @ If:
3.3V @ 18A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
300ns
-
Current - Reverse Leakage @ Vr:
100µA @ 1200V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Supplier Device Package:
TO-263AB
-
Operating Temperature - Junction:
-55°C ~ 175°C
-
Base Part Number:
ISL9
-
detail:
Diode Standard 1200V 18A Surface Mount TO-263AB
