دیتاشیت FSDM0465REWDTU

مشخصات دیتاشیت

دانلود دیتاشیت FSDM0465RE, FSDM0565RE, FSDM07652RE	FSDM0465RE, FSDM0565RE, FSDM07652RE Datasheet

RoHS: true
Category: Power Supply Chip/AC-DC Controllers & Regulators
Datasheet: onsemi FSDM0465REWDTU
Package: TO-220-6(Forming)
Manufacturer: onsemi
Series: FPS™
Packaging: Tube
Part Status: Not For New Designs
Output Isolation: Isolated
Internal Switch(s): Yes
Voltage - Breakdown: 650V
Topology: Flyback
Voltage - Start Up: 12V
Voltage - Supply (Vcc/Vdd): 8V ~ 20V
Duty Cycle: 82%
Frequency - Switching: 66kHz
Power (Watts): 56W
Fault Protection: Current Limiting, Over Load, Over Temperature, Over Voltage
Control Features: -
Operating Temperature: -25°C ~ 85°C (TA)
Package / Case: TO-220-6 Full Pack, Formed Leads
Supplier Device Package: TO-220F-6L (Forming)
Mounting Type: Surface Mount
Base Part Number: FSDM04
detail: Converter Offline Flyback Topology 66kHz TO-220F-6L (Forming)
