MMBF4416A دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MMBF4416A
|
|
حجم فایل
|
57.414
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi MMBF4416A
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
225mW
-
Total Gate Charge (Qg@Vgs):
-
-
Drain Source Voltage (Vdss):
35V
-
Input Capacitance (Ciss@Vds):
4pF@15V
-
Continuous Drain Current (Id):
-
-
Gate Threshold Voltage (Vgs(th)@Id):
-
-
Reverse Transfer Capacitance (Crss@Vds):
0.8pF@15V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
-
-
Package:
SOT-23
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Transistor Type:
N-Channel JFET
-
Frequency:
400MHz
-
Gain:
-
-
Voltage - Test:
15V
-
Current Rating (Amps):
15mA
-
Noise Figure:
4dB
-
Current - Test:
5mA
-
Power - Output:
-
-
Voltage - Rated:
35V
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Base Part Number:
MMBF44
-
detail:
RF Mosfet N-Channel JFET 15V 5mA 400MHz SOT-23-3
