TIP30C Datasheet
Datasheet specifications
| Datasheet's name | TIP30C |
|---|---|
| File size | 171.008 KB |
| File type | |
| Number of pages | 9 |
Download Datasheet TIP30C |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Package: TO-220
- Manufacturer: SPTECH
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Transistor Type: PNP
- Current - Collector (Ic) (Max): 1A
- Voltage - Collector Emitter Breakdown (Max): 100V
- Vce Saturation (Max) @ Ib, Ic: 700mV @ 125mA, 1A
- Current - Collector Cutoff (Max): 300µA
- DC Current Gain (hFE) (Min) @ Ic, Vce: 15 @ 1A, 4V
- Power - Max: 2W
- Frequency - Transition: -
- Operating Temperature: 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: TIP30
- detail: Bipolar (BJT) Transistor PNP 100V 1A 2W Through Hole TO-220AB
