BCP68 数据手册
其他文档
BCP68 2 pages
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Transistor Type: NPN
- Current - Collector (Ic) (Max): 1A
- Voltage - Collector Emitter Breakdown (Max): 20V
- Vce Saturation (Max) @ Ib, Ic: 500mV @ 100mA, 1A
- Current - Collector Cutoff (Max): 10µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 85 @ 500mA, 1V
- Power - Max: 1.5W
- Frequency - Transition: -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-261-4, TO-261AA
- Supplier Device Package: SOT-223-4
- Base Part Number: BCP68
