دیتاشیت BAT54T1G
مشخصات دیتاشیت
| نام دیتاشیت |
BAT54T1G
|
| حجم فایل |
83.496
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi BAT54T1G
-
Reverse Voltage (Vr):
30V
-
Forward Voltage (Vf@If):
800mV@100mA
-
Reverse Leakage Current (Ir):
2uA@25V
-
Average Rectified Current (Io):
200mA
-
Package:
SOD-123
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
30V
-
Current - Average Rectified (Io):
200mA
-
Voltage - Forward (Vf) (Max) @ If:
1V @ 100mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Reverse Recovery Time (trr):
5ns
-
Current - Reverse Leakage @ Vr:
2µA @ 25V
-
Capacitance @ Vr, F:
10pF @ 1V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Operating Temperature - Junction:
125°C (Max)
-
Base Part Number:
BAT54
-
detail:
Diode Schottky 30V 200mA Surface Mount SOT-23-3
