دیتاشیت BAT54HT1G
مشخصات دیتاشیت
| نام دیتاشیت | BAT54HT1 Datasheet |
|---|---|
| حجم فایل | 52.461 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت BAT54HT1 Datasheet |
BAT54HT1 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi BAT54HT1G
- Reverse Voltage (Vr): 30V
- Forward Voltage (Vf@If): 800mV@100mA
- Reverse Leakage Current (Ir): 2uA@25V
- Average Rectified Current (Io): 200mA
- Package: SOD-323
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30V
- Current - Average Rectified (Io): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800mV @ 100mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5ns
- Current - Reverse Leakage @ Vr: 2µA @ 25V
- Capacitance @ Vr, F: 10pF @ 1V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-76, SOD-323
- Supplier Device Package: SOD-323
- Operating Temperature - Junction: -55°C ~ 150°C
- Base Part Number: BAT54
- detail: Diode Schottky 30V 200mA (DC) Surface Mount SOD-323
